Fuelab 529 Series Electronic Fuel Pressure Regulator -8AN EFI 25-90 PSID - Gold

Fuelab 529 Series Electronic Fuel Pressure Regulator -8AN EFI 25-90 PSID in Gold (flb52902-5). The Fuelab 529 Series is an electronic fuel pressure regulator that works with Fuelab Prodigy and H/E Series pumps to deliver fuel on demand. Pressure is set mechanically like a conventional bypass regulator, and the regulator then signals the pump to control return line flow. This version uses -8AN ports.

Key Features

• Demand based flow control that detects a change in demand before rail pressure changes (U.S. Patent 7,810,470)
• Automatically reduces pump current draw at low flow demand
• Works with Fuelab Prodigy and H/E Series pumps and the Fuelab 72002 controller
• Independent system with no additional control boxes or calibration required
• Monitoring capability to track actual fuel system capacity
• Fittings and wiring harness included
• -8AN inlet and return ports, 25-90 PSID EFI range
• Machined from 6061-T6 billet aluminum, hand assembled and serialized
• Anodized per military spec MIL-A-8625, Type II
• Gasoline, diesel, methanol and ethanol compatible

Fitment

Universal application. This is a universal fuel pressure regulator and is not specific to a vehicle year, make or model. Select by port size, seat size and pressure range to suit your fuel system.

Product Details

• Brand: Fuelab
• Series: 529 Series Electronic Fuel Pressure Regulator
• Inlet Port: -8AN
• Return Port: -8AN
• Seat: Standard Seat
• Pressure Range: 25-90 PSID (EFI)
• Finish: Gold
• Included: Fittings and wiring harness
• Warranty: Fuelab limited lifetime warranty
