MAHLE Performance PC479 Ductile Second Compression Ring 5.005in Bore 48-Pack
⚠ Call for Availability
This item may be on backorder. Please contact us to confirm supplier availability and estimated lead time before ordering.
Regular price
$3,563.66
Verified Fitment & Application Support
This product is selected for proper fitment and compatibility with the listed engine application. Our team is available to assist with fitment questions, installation considerations, and supporting components to ensure a smooth install and reliable performance.
Got Questions? Feel free to email us or call us at (503) 235-1947
Compliance & Restrictions
California Proposition 65 (Prop 65)
WARNING: This product can expose you to chemicals which is known to the State of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov.
CARB / California Emissions Compliance
This item may be restricted in California and other regions with emissions regulations. If applicable, it is intended for
competition/off-road use only unless otherwise stated. It is the customer’s responsibility to confirm local compliance before purchase.
Orders shipping to restricted areas may be canceled.
Open-stock second compression ring for 5.005in bore, .043in axial height, from the MAHLE Performance ring range. It is built from PC479 hardened ductile iron.
Key Features
- Second ring duty is roughly 80% oil control and up to 20% compression control
- PC479 is a hardened high strength nodular iron. The extra hardening process lets the ring run against most bore surfaces without an additional face coating, which is why MAHLE uses it in power adder applications that exceed what a conventional face-coated ring will tolerate.
- Supplied as a bulk open-stock pack of 48 rings
Product Details
- Brand: MAHLE Performance
- Product type: Second Compression Ring
- Bore diameter: 5.005 in
- Axial height: .043in
- Radial wall thickness: .190 in
- Base material: PC479 hardened ductile iron
- Face coating: PC479
- Position: Lower compression ring (second)
- Pack quantity: 48
- Manufacturer Part Number: 302-1140B
